Description
Meet the 2025 TYPHON TERROR XX — a robust 4,000 lb mini excavator engineered for performance, stability, and precision. Built around the reliable Kubota D902 engine, this model is ideal for contractors, landscapers, and farmers who need serious digging power in a compact footprint.
🔧 Key Features
-
Engine: Kubota D902, 3-cylinder, water-cooled diesel engine, 20.4 HP @ 3,600 RPM
-
Operating Weight: 4,000 lbs (1,814 kg)
-
Bucket Capacity: 0.045 m³ (1.59 ft³)
-
Max Digging Depth: 5.9 ft (1.8 meters)
-
Max Digging Reach: 9.5 ft (2.9 meters)
-
Hydraulic Pressure: 24.5 MPa
-
Swing Radius: 970 mm (3’2″)
-
Ground Clearance: 380 mm (15″)
-
Fuel Tank: 45 liters
-
Hydraulic Oil Tank: 41 liters
-
Boom Swing: 70° left / 70° right
-
Cabin: Enclosed for added protection and control
-
Track Type: Rubber track for reduced ground disturbance
-
EPA Certified: Yes — meets U.S. emission standards
📊 Technical Specifications
| Engine Model | Kubota D902 |
| Horsepower | 20.4 HP @ 3,600 RPM |
| Operating Weight | 4,000 lbs (1,814 kg) |
| Bucket Capacity | 0.045 m³ (1.59 ft³) |
| Max Digging Depth | 5.9 ft (1.8 meters) |
| Max Digging Reach | 9.5 ft (2.9 meters) |
| Hydraulic Pressure | 24.5 MPa |
| Swing Radius | 970 mm (3’2″) |
| Ground Clearance | 380 mm (15 inches) |
| Fuel Tank Capacity | 45 liters |
| Hydraulic Oil Capacity | 41 liters |
| Boom Swing | 70° left / 70° right |
| Cabin Features | Enclosed |
| EPA Certification | Yes |
🚚 Shipping & Delivery
-
Standard Delivery: 15–25 business days — Free
-
Express Delivery: 7–10 business days — $249
-
Unloading: No forklift needed — trucks arrive equipped with ramps for easy ground-level unloading
-
Tracking Info: Sent within 24 hours after dispatch
🔄 Return & Warranty Policy
-
Returns: 60-day return policy (unused equipment in original condition)
-
Warranty: 5-year full warranty covering parts and performance defects
📦 What’s Included
-
1 × 2025 TYPHON TERROR XX 4,000 lb Mini Excavator
-
1 × Standard digging bucket
-
1 × Operator canopy
-
1 × Tool kit
-
1 × Digital user manual
🧰 Attachments Included (12-in-1 Package)
This excavator includes 12 premium attachments designed for digging, grading, lifting, and breaking:
-
1 × 200mm Trenching Bucket — For narrow trenches and utility runs
-
1 × 500mm Ditching Bucket — Ideal for light grading and slope work
-
1 × 600mm Skeleton Screening Bucket — For separating debris and rocks
-
1 × Hydraulic Auger — Drill precise holes for fencing and planting
-
1 × Mechanical Grapple — Securely grab logs, rocks, and debris
-
1 × Mechanical Thumb — Adds grip for lifting and loading
-
1 × Quick Hitch Coupler — For fast attachment changes
-
1 × Ripper Tooth — Break up compact ground or roots
-
1 × Landscape Rake — Clear brush and prep land
-
1 × Tilting Grading Bucket — Shape terrain and ditches easily
-
1 × Standard Bucket (Mounted)
-
1 × Heavy-Duty Trenching Blade — For sharp-edged trench shaping
🛠️ Applications
-
General excavation and trenching
-
Landscaping and material handling
-
Residential and commercial construction
-
Ditch clearing and public works
-
Rock breaking and orchard management
The 2025 TYPHON TERROR XX delivers dependable strength, cabin comfort, and multi-attachment capability, making it an elite choice for professionals who demand more from their equipment.
