Description
The TYPHON TERROR XX Mini Excavator combines luxury, efficiency, and robust performance in a compact design. Powered by the reliable Kubota D902 diesel engine and EPA certified, it’s engineered for versatility across various applications, from landscaping to construction.
🔧 Key Features
-
Engine: Kubota D902, 3-cylinder, water-cooled diesel engine delivering 20.4 HP at 3,600 RPM
-
Operating Weight: 4,000 lbs (1,814 kg)
-
Bucket Capacity: 0.045 m³ (1.59 ft³)
-
Max Digging Depth: 5.9 ft (1.8 meters)
-
Max Digging Reach: 9.5 ft (2.9 meters)
-
Hydraulic Pressure: 24.5 MPa
-
Swing Radius: 970 mm (3’2″)
-
Fuel Tank Capacity: 45 liters
-
Hydraulic Oil Tank Capacity: 41 liters
-
Ground Clearance: 380 mm (15 inches)
-
Boom Swing Functionality: Enhanced maneuverability with 70° left and right swing
-
Cabin Comfort: Spacious cabin with ergonomic controls
-
EPA Certified: Compliant with U.S. emission standards
📊 Technical Specifications
| Engine Model | Kubota D902 |
| Horsepower | 20.4 HP @ 3,600 RPM |
| Operating Weight | 4,000 lbs (1,814 kg) |
| Bucket Capacity | 0.045 m³ (1.59 ft³) |
| Max Digging Depth | 5.9 ft (1.8 meters) |
| Max Digging Reach | 9.5 ft (2.9 meters) |
| Hydraulic Pressure | 24.5 MPa |
| Swing Radius | 970 mm (3’2″) |
| Ground Clearance | 380 mm (15 inches) |
| Fuel Tank Capacity | 45 liters |
| Hydraulic Oil Capacity | 41 liters |
| Boom Swing | 70° left / 70° right |
| Cabin Features | Ergonomic controls |
| EPA Certification | Yes |
📦 Shipping & Delivery
-
Standard Delivery: 15–25 business days — Free
-
Express Delivery: 7–10 business days — $249
-
Unloading: Ground-level ramp unloading included — no forklift required
-
Tracking: Dispatched within 24 hours of shipment
🔄 Return & Warranty Policy
-
Returns: 60-day return window from delivery (unused & in original condition)
-
Warranty: 5-year full warranty covering parts and manufacturer defects
📦 What’s Included
-
1 × 2025 4,000 lb TYPHON TERROR XX Mini Excavator
-
1 × Standard digging bucket
-
1 × Operator canopy for protection
-
1 × Tool kit
-
1 × Digital user manual
🧰 Attachments Included (12-in-1 Package)
Unlock unmatched flexibility with a complete 12-in-1 attachment set designed to tackle everything from digging to grading:
-
1 × 200mm Trenching Bucket — Ideal for narrow digging paths
-
1 × 500mm Mud Bucket — Moves large volumes of loose soil
-
1 × 600mm Skeleton Bucket — Efficient rock and debris separation
-
1 × Hydraulic Auger — Bore fence post holes or tree pits fast
-
1 × Mechanical Grapple — Secure material handling made easy
-
1 × Mechanical Thumb — Provides firm grip during material lifts
-
1 × Quick Hitch — Tool-free, fast swapping of attachments
-
1 × Ripper Tooth — Breaks tough soil and root systems
-
1 × Landscape Rake — Perfect for finishing work and surface clearing
-
1 × Tilting Grading Bucket — Precision slope and terrain shaping
-
1 × Trenching Blade — Clean trench wall cutting
-
1 × Standard Bucket (Pre-mounted)
🛠️ Applications
-
Landscaping and gardening
-
Construction projects
-
Trenching and digging
-
Ditch cleaning
-
Rock breaking and debris removal
-
Public works and municipal maintenance
-
Farming and orchard management
The 2025 TYPHON TERROR XX Mini Excavator offers a blend of power, precision, and comfort, backed by a full attachment package — making it an elite solution for pros who demand reliability and results in every dig.
